HYDRAULIC FILTER SPIN ON
PFH56659
HYDRAULIC FILTER SPIN ON
PFH56659
£64.96 exc VAT
Order By 2pm for UK Free Next Day Delivery
Orders under £250 Standard Delivery £25 +VAT
Orders over £250 Free Delivery
| Product Specification | |
| Thread Size | 2 x 16 UN |
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 70 mm (2.76 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 177 mm (6.97 inch) |
| Overall Length | 177 mm (6.97 inch) |
| Anti Drain Back Valve | No |
| Bypass Valve | Yes |
| Bypass Valve Setting LR | No |
| Bypass Valve Setting HR | No |
| Collapse Burst | 2.8 bar 41 psi |
| Efficiency 99.9% Beta 1000 | 11 micron |
| Efficiency 99.9% Beta 1000 | 23 micron |
| Efficiency Test Standard | ISO IATF 16949 |
| Type | OEM Quality Hydraulic Filter |
| Style | Hydraulic Spin On |
| Media Type | Synthetic Pleated |
| Notes | Bottom End Closed |
| Notes | Gasket Seal Included |
| Notes | Square Seal is Attached |
| Notes | |
| Primary Application | TEREX Z6550537 |
OEM Cross Reference
| Manufacturer Name | Manufacturer Part No |
| ASAS | SP1128H |
| ASAS FILTER | SP1128H |
| BALDWIN | BT9400MPG |
| CASE IH | 76086226 |
| DANA | 4209440 |
| DANA | D4209440 |
| DONALDSON | P765075 |
| FLEETGUARD | HF35464 |
| FLUITEK | FLK1800200 |
| HIFI FILTER | SH66201 |
| HYSTER | 1556992 |
| JLG | 8008101 |
| KALMAR | 9210280007 |
| KALMAR | 4258178279 |
| LOESING | 140522 |
| MAHLE | HC58 |
| PALLMAN | PFH56659 |
| PALLMAN FILTER | PFH56659 |
| PARKER HANNIFIN | BT9400MPG |
| SF FILTER | SPH12554 |
| SMV | 8802003 |
| SURE FILTER | SFH5075 |
| TEREX | Z6550537 |
| TEREX | TFC45H |
| TEREX | 10035430 |
| TOTAL SOURCE | 9364243 |
| WIX | 57227 |
| YALE | 580048036 |
Machinery & Equipment
| Equipment | Year | Equipment Type | Equipment Options | Engine |
| HYSTER H700FT | FORKLIFT | HYSTER H700FT | ||
| KALMAR DRF450 60S5 | FORKLIFT | VOLVO TAD1360VE | ||
| KALMAR DRF450 60S5 | FORKLIFT | VOLVO TWD1240VE | ||
| NEW HOLLAND LM1333 | TELEHANDLER | NEW HOLLAND LM1333 | ||
| NEW HOLLAND LM1440 | TELEHANDLER | NEW HOLLAND LM1440 | ||
| YALE GDP 120 DB | FORKLIFT | GDP SERIES | YALE GDP 120 DB |
